VD-288Z-14 - GUTEKUNST United States

---

Description: Material EN 10270-3-1.4310 - Type of material Spring ends Closed and ground - Spring ends F1 N prestressed spring force L1 mm Prestressed spring length s1 mm Prestressed spring deflection F2 N Loaded spring force L2 mm Loaded spring length s2 mm Loaded spring deflection d 3 mm Wire diameter Di mm Inner coil diameter D 34 mm Mean coil diameter De 37 mm Outer coil diameter Dd 30.1 mm maximum diameter of mandrel Dh 38.5 mm minimum diameter of bush L0 190 mm unstressed spring length Lk 93.06 mm buckling length Fn 195.509 N maximum force in static use Ln 54.48 mm Minimum length in static use sn 135.53 mm Maximum spring deflection in static use Fndyn 187.581 N maximum force in dynamic use Lndyn 59.97 mm Minimum length in dynamic use shdyn 50.41 mm Maximum stroke in dynamic use S 14.96 mm pitch of spring n 12.5 pc. number of active coils nt pc. total number of coils R 1.443 N/mm Spring rate Fntol 12.36 N (+/-) tolerance of maximum force in static use Fndtol 12.22 N (+/-) tolerance of maximum dynamic force Detol 0.6 mm (+/-) tolerances of outer coil diameter L0tol 5.33 mm (+/-) tolerance of unstressed spring length Price group R - price group F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Weight Approx: 0,090 kg/ea

---

PLEASE CONTACT US TO ORDER TO GET THE BEST PRICE AND DELIVERY FOR GUTEKUNST BRANDED VD-288Z-14 YOU MAY ASK FOR SOME OTHER PART NUMBER AS WELL. WE CAN OFFER BEST PRICE AND DELIVERY WITH WIDE PRODUCTS DISTRIBUTION NETWORK IN USA AND THROUGHOUT THE WORLD IN INDUSTRIAL PRODUCTS MARKET.
